Ref No
Part Number
Description
Serial Range
Qty
Price

Ref No
1
Part Number
23510-VA2-700
Description
GEAR, PINION (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$22.08

Ref No
2
Part Number
23512-952-771
Description
HOLDER, RATCHET (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$9.34

Ref No
3
Part Number
23513-952-770
Description
RATCHET
Serial Range
1000001 - 9999999
Qty
Price
$4.05

Ref No
4
Part Number
23514-960-770
Description
SPRING, RATCHET RETURN
Serial Range
1000001 - 9999999
Qty
Price
$2.06

Ref No
4
Part Number
23514-VA9-K40
Description
SPRING, RATCHET RETURN (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$1.07

Ref No
5
Part Number
23515-960-770
Description
CAP, PINION GEAR (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$7.58

Ref No
6
Part Number
42810-VA2-701
Description
WHEEL, RR.
Serial Range
1000001 - 1072629
Qty
Price
$48.29

Ref No
6
Part Number
42810-VA2-703
Description
WHEEL, RR.
Serial Range
1072630 - 9999999
Qty
Price
$48.29

Ref No
7
Part Number
42812-VA2-701
Description
HUB, WHEEL
Serial Range
1000001 - 1072629
Qty
Price
$32.94

Ref No
7
Part Number
42812-VA2-702
Description
HUB, WHEEL
Serial Range
1072630 - 9999999
Qty
Price
$32.94

Ref No
8
Part Number
42751-VA3-J00
Description
TIRE (8 INCH)
Serial Range
1000001 - 9999999
Qty
Price
$18.90

Ref No
9
Part Number
42865-VA2-700
Description
COVER, WHEEL (NOT AVAILABLE)
Serial Range
1000001 - 9999999
Qty
Price
$11.38

Ref No
10
Part Number
42930-VA2-700
Description
ARM, R. RR. ADJUSTING
Serial Range
1000001 - 9999999
Qty
Price
$18.96

Ref No
11
Part Number
42940-VA2-700
Description
ARM, L. RR. ADJUSTING (NOT AVAILABLE)
Serial Range
1000001 - 9999999

Ref No
12
Part Number
42944-VA2-702
Description
DUST SEAL (12MM)
Serial Range
1000001 - 9999999
Qty
Price
$2.51

Ref No
13
Part Number
42952-952-000
Description
GRIP, ADJUSTER
Serial Range
1000001 - 9999999
Qty
Price
$2.64

Ref No
14
Part Number
42961-VA2-700
Description
PLATE, RR. ADJUSTING
Serial Range
1000001 - 9999999
Qty
Price
$6.75

Ref No
15
Part Number
90110-VA4-000
Description
BOLT, WHEEL
Serial Range
1000001 - 9999999
Qty
Price
$2.27

Ref No
16
Part Number
90403-952-770
Description
WASHER, PLAIN (22MM)
Serial Range
1000001 - 9999999
Qty
Price
$1.66

Ref No
17
Part Number
90452-708-000
Description
WASHER (12MM)
Serial Range
1000001 - 9999999
Qty
Price
$0.77

Ref No
19
Part Number
90486-028-000
Description
WASHER, SPARK ADVANCER SETTING
Serial Range
1000001 - 9999999
Qty
Price
$1.50

Ref No
20
Part Number
91055-VA2-700
Description
BEARING, RADIAL BALL
Serial Range
1000001 - 9999999
Qty
Price
$6.85

Ref No
21
Part Number
92101-06012-0A
Description
BOLT, HEX. (6X12)
Serial Range
1000001 - 9999999
Qty
Price
$1.02

Ref No
22
Part Number
93892-04014-08
Description
SCREW-WASHER (4X14)
Serial Range
1000001 - 9999999
Qty
Price
$0.78

Ref No
23
Part Number
94511-22000
Description
CIRCLIP (OUTER) (22MM)
Serial Range
1000001 - 9999999
Qty
Price
$0.91
